40′ x 40′ x 16′ Steel Building Sale
Create your own personal 40′ x 40′ x 16′ steel building sale by recommending the profit amount. Factory Steel Overstock’s cost-plus program is the ideal selling dynamic for informed buyers.
Specifications for 40′ x 40′ x 16′ I-Beam Steel Building
Factory Steel Overstock’s (FSO) 40’x 40′ x 16′ I-Beam Steel Building has a 40-year Warranty on Colored Walls and Trim| Solid I-Beam Construction |Clear span design (no interior columns)|Lifetime Structural Warranty | Complete Sculptured Trim Package | Framed Openings Fully Flashed |30 Yr. Warranty: Galvalume Plus Roof Finish or 40-Year Warranty on Colored Roof | 26 Gauge sheeting -80,000 p.s.i. tensile strength -1 1/4″ sheeting profile| Purlin bearing rib (PBR panels – larger overlap than R panels). All panels incorporate the purlin bearing profile, along with long-life roof fasteners that match the selected building colors.| All bolts, screws, closures, weather stripping, sealants, fasteners as required to erect structure| The pre-punched connecting clips for the structural members, including endwall columns, are welded in place and then primed during fabrication | All structural elements for the specified framed openings (jamb, girts and headers) are pre-cut and pre-punched and the necessary clips are welded on during fabrication | Anchor bolts and erection services by other. The manufacturer has IAS accreditation, as well as MBMA (Metal Building Manufacturers Association) membership.
The 40′ x 40′ x 16′ Cost-Plus Buying Program
It is rare to find a company offering a true 40′ x 40′ x 16′ Cost-Plus Buying Program. Well, you just did!
Instead of waiting for an obvious retail quote from a commission-based salesperson, FSO allows the general public to use its Metal Building Wholesale Calculator to determine accurate wholesale delivered rates. After the consumer has compared these rates, prepared buyers can fill out a cost-plus quote form. They will receive a quote of the actual 40′ x 40′ x 16′ wholesale price, wherein they will present what they feel is a fair profit amount. This unique approach unifies buyers and sellers instead of pitting them against each other.
Video: How to receive a wholesale price.
Video: Our building features are other companies’ options
Metal Building Wholesale Calculator
The general public can use the Metal Building Wholesale Calculator to determine real rates delivered throughout the US.
Purchase a 40′ x 40′ x 16′ Metal Building Package Model
Below are the Economy, Standard, Deluxe, and Executive Models with specific features and accessories included. Whether you want a 40′ x 40′ x 16′ or 100′ x 200′ x 16′, Factory Steel Overstock efficiently offers certified IAS structures at wholesale rates. The general public simply offers a fair profit amount to complete the sales transaction.
Economy
1:12 Pitch
Included: 30-year Galvalume plus roof finish..1-Fully Flashed F/O. 40-year color wall and trim finish, 1-3′ x 7′ Insulated Commercial Walk Door
Standard
4:12 Pitch
Included: 40-year Color roof, wall, and sculptured trim finish. 1-Fully Flashed F/O. 1-3′ x 7′ Insulated Commercial Walk Door.
Deluxe
3:12 Pitch
Included: A beautiful 2′ Purlins & Canopy Extensions with soffits. Gutters & Downs, 1-Fully Flashed F/O. 1-3′ x 7′ Insulated Commercial Walk Door. 40-year color roof, wall, and sculptured trim.
Executive
3:12 Pitch
Included: An attractive 2‘ Purlin and Canopy Extension with soffits. An appealing 4’ Wainscot with transition trim. Gutters & Downs, 1-Fully Flashed F/O. 40-year color roof, wall, and sculptured trim finish. 1-3′ x 7′ Insulated Commercial Walk Door.
Four 40’x 40′ x 14′ Buying Steps
- Get one or more market quotes
- Fill-our a custom quote form
- After receiving and actual wholesale price, suggest a fair profit amount.
- If the offer is accepted, pay that amount on the same day.
Standard I-Beam Steel Building Specifications
Free (Initial) Certified Building Plans for ALL 50 states.
- Letter of Certification
- 2 sets of certified stamped anchor bolt plans
PRIMARY FRAMING
(Mainframes)
SOLID I-BEAM CONSTRUCTION Material used is 34,000 and 55,000 p.s.i. yield strength. (Some manufacturers use only 34,000 p.s.i. yield strength material). Frames are single bead, continuous submerged arc welded by automatic welding machines to help ensure quality. A factory-applied rust inhibiting primer is used to help protect the mainframes and secondary material during the erection process.
ENDWALL FRAMES AND COLUMNS are either cold formed, hot-rolled or built-up “I” sections depending on design requirements.
SECONDARY FRAMING
GIRTS (in sidewall) and PURLINS (in roof) are minimum 8” to meet design requirements. Cold rolled Z-section, 12 to 16 ga ASTM A-653, 55,000 p.s.i. yield material is used to provide maximum strength.
Bypass girt system overlaps at sidewall columns forming a continuous “span” for extra strength. All girt clips are factory welded for easier erection.
PURLINS are top-mounted on the rafter with a varied lap of 1’6” to 5’ for strength and cost savings in erection labor. Maximum purlin spacing is 5’ on center.
EAVE STRUT is a cold-formed C-section that is rolled for the appropriate roof pitch to help insure weather tightness at the eave.
RAKE ANGLE is a 2×4 angle supplied for the attachment of the sheeting at the rake of the building for ease of installation.
BASE ANGLE is a 2×4 angle supplied for the attachment of the base of the sheeting to the concrete. The base angle is to be attached to the concrete with ram-sets or equivalent anchors.
BRACING All diagonal galvanized cable bracing is supplied for roof and walls to remove longitudinal load from the structure. Galvanized cable is used rather than solid rod to prevent the bracing from “sagging” under its own weight and it is easier to install. All cables are pre-stressed and pre made for easier erection.
Angle Flange Bracing is provided for the connection of the rigid frame to the purlins and girts. This ensures the allowable compressions are adequate for any combination of loading.
FRAMED OPENINGS have cold-formed C-section jambs and headers to help insure easy installation of overhead doors, etc.
SHEETING
26 gage 80,000 P.S.I. yield strength material standard. Some manufacturers use a lower yield strength material, which is less resistant to damage from hail or other impacts.
ALL COIL STEEL has a minimum of G-90 class Galvalume substrate (1.25oz hot dipped) to help prevent deterioration of the steel sheeting.
DEEPER HIGH-RIB with more frequent corrugations provides extra strength.
OPTIONAL ARCHITECTURAL PANEL configuration is available for walls, mansard systems, soffit material, etc., to add an aesthetic appeal to your building.
FASTENERS
STRUCTURAL BOLTS meet requirements ASTM Standards. A-325 for primary frame connections A-307 for secondary framing
SELF-DRILLING AND SELF-TAPPING FASTENERS are pre-assembled with neoprene washers and metal caps to help insure weather tightness.
CLOSURES
CLOSED CELL NEOPRENE STRIPS are used to help seal building. Located at eave, gable, and optional at the base of building to help provide weather tightness. Pre-formed shapes to match panel configuration providing a tighter seal.
1-1/2” SHEETING NOTCH at base of concrete where panel site is designed into every building. Sheeting notch provides an air infiltration stop on blanket insulated building.
SEALANTS
SEALANT for roof sidelaps, endlaps and flashing at gable is provided to help insure weather tightness. Nominal 3/8” x 1/8” thick pressure sensitive tape sealant for ease of installation.
RIDGE CAP
LONG OVERLAP to help prevent water from siphoning into building.
TRIM AND FLASHING
All buildings are fully trimmed at rake (gable), corners, and eaves with standard trim material for a more finished look. This not only improves look of building, it is an additional deterrent to moisture, insects, and dirt from getting into the building.
PLANS AND DRAWINGS
ANCHOR BOLT setting plan, building reactions for foundation design, Erection Manual, and Engineer Letter of Certification is provided shortly after receipt of deposit for building.
ERECTION DRAWINGS provide step-by-step instructions for the case of assembly by dealer or customer.
ENGINEER CERTIFIED APPROVAL DRAWINGS including wall and roof framing diagrams, cross sections, sheeting, and flashing details are provided. These drawings clearly show the proper erection and assembly of all building components.
ALL PARTS ARE NUMBERED Part number is placed on each component (not including sheeting, screws, etc.). These part numbers coincide with a detailed listing contained in the bill of materials that comes with your building. The same numbers are also used on the drawings for clarity and to help with assembly on the job site.
For more details, click Specifications
40′ x 40′ x 14′ Metal Building Colors
You will list your colors on the Predesign Building Quote-Order Form.
The building colors have a 40-year warranty. Galvalume Plus color has a 30-year warranty.
***Roll Up Door colors are posted below WALL and TRIM color swatches.***
