High R-Value Reflective Insulation – R-17
The PRODEX High R-Value 17 Reflective Insulation is perfect for metal buildings and pole barns. It is light and easy to cut and install, and you can quickly retrofit it into existing structures. It is considered the preferred DYI type. Some have labeled it Woven R-17 because of its specifications (listed in the tab below).
Our R-Value 17 Reflective Insulation has an adhesive running down the 175′ length. This insulation is a Radiant Barrier, a Vapor Barrier, and an Air Barrier -which is imperative for metal buildings and pole barns. It is also an ideal solution for heat, cold, condensation, and air! Primarily the R-value 17 reflective insulation is a strong seller in medium to hot climates. The best part, this insulation is can be delivered as quickly as seven 7 days.
Roll Size 4’ x 175’ (700 sq. ft). 5 mm thickness (0.4”)
Reflective Insulation Is Ideal for Metal Buildings
Reflective Insulation, despite its lightweight, is just as effective as fiberglass for energy efficiency. Many customers choose it for their metal buildings and pole barns because it is not cumbersome and bulky like fiberglass when installing. The applied adhesive running down one side of each roll eliminates the need for reflective tape to seal the seam, and some customers opt for double-sided adhesive to further secure the insulation during installation. This time-saving features can reduce installation time by up to 50%, a significant benefit that resonates with customers.
Reflective Insulation Online Calculator
The High R-Value 17 reflective insulation is resistant to moisture and pests. The outer layer of insulation helps prevent common issues such as mold and mildew growth and damage from rodents or insects. However, what appeals to everyone is the fantastic price for the high 97% radiant barrier effectiveness. Call 1-888-512-1116 for a wholesale quote!
Reflective Insulation Order Form
R-Value 17 Reflective Insulation Details
R-Value 17 Reflective Insulation Features
Fuses the advantages of insulation with defenses against vapor, air, and radiant heat. This ensures your structure remains cool and moisture-free in the hotter months, and cozy and dry during the colder seasons.
Performs excellently in both warm and cool environments. Beyond being the premier choice for insulating metal buildings, it serves as an essential element in an all-encompassing residential insulation system.
- Available High R-Value – 15.3 (white facing), 17 and 22 (reinforced reflective facing)
- It is ICC-ES Recognized
- R-Value unaffected by outside humidity
- It prevents 97% of radiant transfer (the primary source of heat flow)
- Is a vapor barrier
- Prevents condensation
- 19 dba contact noise reduction
- 90 Celsius (194 F) contact temperature rating
- UV resistance
- Center is polyethylene foam instead of air bubbles.
- Material does not allow mold or mildew
- Does not provide for nesting or rodents, bugs or birds
- Easy seals around nails (no leaks)
- 100% recyclable virgin raw materials; therefore eco -friendly.
- Its surface keeps it airflow
- Lighter weight; therefore, less cumbersome installation than fiberglass batt
- Significant price savings over fiberglass batt and spay of same R-Value standard
- Delivery times (fiberglass average delivery is 2 to 3 weeks vs. reflective is 7 to 10 days).
Reflective insulation primarily works by reflective radiant heat instead of absorbing like other insulation types. Here are 4 advantages:
- Reflective insulation saves your utilities cost because it reflect the radiant heat away from your structure.
- Most consider it the most accessible insulation to install. It is lightweight and can be easily cut with a knife. It is simply the perfect DIY insulation product.
- Reflective insulation is versatile. You can used it in steel structures, pole barns, attics, floors, around pipes, and craw spaces..
- It is a star for hot climates. If you are in a hot area, its reflective materials will reflect the sun’s radiant energy away from your structure.
Resistance to Growth of Fungi
- Aspergillus niger
- Aspergillus avus
- Aspergillus versicolor
- Penicillium funiculosum
- Chaetomium globosum
- ASTM C 1338
R-Value Reflective Insulation Specifications
- 4′ x 175′ (700′ per roll)
- Adhesive along one side of the 175′ roll.
- 5 mm thickness
- Improve tear resistance
- Flame Spread – ZERO
Insulation Layered
- Reflective reinforced foil
- Polyethlene foam
- Reflective reinforced foil
| Characteristics | Value | Regulation |
| Nominal Thickness | 0.20″ (5mm) | |
| Flame Spread Index | 0 | ASTM E 84-10 |
| Smoke Developed Index | 5 | ASTM E 84-10 |
| Fungi Resistance | No Growth | ASTM C 1338 |
| Cell Structure | Closed | |
| Water Vapor Permeance | 0.011 Perms | ASTM E 96-05 |
Resistance to Temperature and Humidity: Exhibits no signs of corrosion, delamination, or deterioration in metalization as per ASTM C-1258-08 standards.
Factory Steel Overstock’s High R-Value Reflective Insulation is the best insulation for Pole Barns and Steel Buildings
R-Value 17 Reflective Insulation over Foam Board
Though Foam board insulation is an efficient way to buildings and homes, does come with its set of drawbacks.
- Chemical Ingredients and Environmental Factors: Foam board insulation is made from petrochemicals. In some cases it can contain toxic materials like flame retardants. These materials the quality of indoor air; therefore potentially chasing health issues. In addition, it disposal can have an adverse impact on the environment.
- Moisture Issues: If one doesn’t have a purchase a moisture -resistant foam board, moisture can infiltrate the foam board. This leads to water damage, mold and insulation performance.
- Potential Fire Haszard: Many foam boards are flammable; therefore when used inside must be covered with some kind of a fire-rated material. Needless to say, this adds cost.
- Its about price for most: It simply cost more for materials and installation. If money is not an issue, it definitely has it place for certain applications.
Why R-Value 17 Reflective Insulation over spray foam insulation
Though spray foam insulation offers superior air sealing, high R-values, and is applicable for some construction projects, we do not provide it because…
- It is too expensive
- It doesn’t protect your steel building from radiant heat transfer.
- It is labor extensive, so a professional is required for installation
- A great deal of spray foam can release toxic fumes when it burns
Reflective R17 & 22 Values
Reflective R-Value 15.3
Related Products
Reflective Tape
- Package of 2 rolls – $60
- Package of 8 rolls – $170
- Package of 16 rolls – $312
Reflective tape plays a crucial role! Sealing seams with this tape enhances the efficiency of insulation.
A pack of 8 rolls, each set measures 2.83 inches by 480.8 yards, covers an area of 4500 square feet of insulation.
Pins and Caps
- 1 – $358.95
- 2 – $717.90
$1000 sets of 1-5/8″ pins accompanied by 1- 1/2″ circular lock washers, amounting to 2000 pieces in total. Suggested placement involving one hanger per every 2 square feet. These 14L perforated base insulation hangers are specifically crated for installations of our reflective installation.
Double Sided Tape
- 1 – $100 per package
Double-sided adhesive tape, available in a package of 4 rolls, each being 1-1/2 inches wide and 60 yards long, is designed for securing insulation material to surfaces. This set is capable of effectively serving up to 2000 square feet of insulation area.
Super Metal Sealant
- 1 – $95
- 2 – $190
- 3 – $285
Super Metal Adhesive: Sold in a pack of 12 tubes, this sealant efficiently bonds insulation materials to a wide range of surfaces.
